1.25 years production experience .
2.Materials :carbon steel or stainless
3.ISO9001,ISO14000,SGS .
4.Quality assurance .
| Follow Us: |  |  |  |  |  |
Expansion joint provides superior flexibility and excellent corrosion resistance.Metal Expansion Joint is the solution for many of the most aggressive Exhaust Gas applications.The expansion joints are made generally from thin wall Type ASTM/SA-240 Grade 321Stainless Steel in multiply construction with inner sleeves and various forms of end connectors including fixed and swivel flanges,pipe weld ends,‘V’flanges etc.made from stainless or carbon steel or other alloy material.
|
No |
Name |
Quantity |
Material |
|
1 |
Body |
2 |
QT450-10, Q235A |
|
2 |
Sealing |
1 |
NBR, CR, EPDM |
|
3 |
Follower |
2 |
QT450-10, Q235A |
|
4 |
Limited short pipe |
2 |
Q235A |
|
5 |
Nut |
n |
Q235A, 20# |
|
6 |
Long stud |
n |
Q235A, 35# |
|
7 |
Short stud |
n |
Q235A, 35# |
