Home >Products > Metal Expansion Joint > Ssjb-2 Cov
Ssjb-2 Cover Limited Expension Joint

Product Description

Henan Lanphan Industry Co., Ltd:
1. Since 1988, Top 3 manufacturer of mechanical coupling in China;
2. The Main Drafting Committee of National Standard for Mechanical Coupling;
3. Qualified Supplier for Nuclear Power Plant;
4. ISO9001: 2008 and ISO14001: 2004 Certified.
E-mail:enquiry@lanphan.com
Product Description
Parameter
Order Online
Related Products
Follow Us: Facebookyoububetwittergoogle+linkenin
Product Description

Product Description


Product Description
Product Performance
The product is manufactured through welding or metal casting, and the loosing part is sealed by echelon ring rubber. Operated by gland and bolt and based on the principle of rubber's elastic deformation under pressure, the seal ring will be deformed and static seal will be done between joint body and expansion pipe wall. According to clients demand and product performance, metal and seal ring materials will be selected strictly. High- Strength antifouling paint is painted outside and the joint bolt is made of high- Strength carbon steel or stainless steel, since there is some space between body and expansion, so axes and radial displacement will appear. Inside pipe, it becomes available to compensate and release pipe blind plate propulsion and makes it easy to maintain and change pump and valve. Therefore, it is an ideal matching product for pipe's installation and operation.
Applicable Scope
The metal product is functioned with pull and pressure resistance and excellent seal performance and easy installation. Hence it is widely used in power, metallurgy, drainage and sewage disposal to connect pump, valve and pipe, etc. It also has some multi-directional displacement during pipes' operation so as to release blind plate propulsion and protect pipes, especially it makes it easy to install and maintain pipes. However, force-transferring joints shall be used on the pipe corner and pump exit, because, the joints can transfer blind plate propulsion from pump start to pump and pipe through force- Transferring bolt and prevent pull to centralize close to pipe or pump or damage equipment by impact force. Other joints can be selected freely for other positions. Our tenet: Your trust is our honor and will manufacture high- Quality products for you
Parameter
Name Quantity material
Follower 2 QT450-10,Q235A
Sleeve 1 NBR
Gasket 2 QT450-10,Q235A
Limited short pipe 2 Q235A
nut Tn Q235A,20#
long stud n Q235A,35#
short stud n Q235A,35#




Parameter



DN DW DN Compensation length
65 76 76 90
80 89 89
100 108 108
100 114 114
125 133 133
125 140 140
150 159 159
150 168 168
200 219 219
250 273 273 110
300 325 325
350 377 377
400 426 426
450 480 480
500 530 530
600 630 630
700 720 720 150
800 820 820
900 920 920
1000 1020 1020
1200 1220 1220
1400 1420 1428
1500 1520 1528
1600 1620 1628
1800 1820 1828
2000 2020 2030
2200 2220 2230
2400 2420 2430
2600 2620 2630
2800 2820 2830
3000 3020 3030 260
3200 3220 3230
3400 3420 3432
3600 3620 3632
3800 3820 3832
4000 4020 4034
